| Number of Poles | 8 |
| Number of Phases | 3 |
| Nominal voltage VDC | 24 |
| Product Keywords | Speed Reducer Gearbox BRUSHLESS DC PLANET GEAR MOTOR,Speed Reducer BRUSHLESS DC PLANET GEAR MOTOR,Sewing Machine BRUSHLESS DC PLANET GEAR MOTOR |
|
Housing Material |
Metal |
|
Bearing at output |
Ball Bearings |
|
Radial play of shaft |
≤0.04mm |
|
Thrust play of shaft |
≤0.3mm |
|
Backlash,at no-load |
≤3° |
|
Model |
S42BL41-240 |
S42BL61-240 |
S42BL81-240 |
S42BL101-240 |
|
|
Number ofPoles |
8 |
||||
|
Number ofPhases |
3 |
||||
|
Nominal voltage VDC |
24 |
||||
|
Rated speedRPM |
4000 |
||||
|
Rated TorqueN-m |
0.0625 |
0.125 |
0.185 |
0.25 |
|
|
Rated Current Amps |
1.8 |
3.5 |
5.2 |
6.6 |
|
|
Output Power Watts |
26 |
52 |
78 |
105 |
|
|
Peak Torque N-m |
0.18 |
0.38 |
0.55 |
0.75 |
|
|
Peak Current Amps |
5.4 |
10.5 |
15.6 |
20 |
|
|
Torque constantN-m/A |
0.041 |
0.041 |
0.041 |
0.041 |
|
|
Back EMFV/k RPM |
4.36 |
4.36 |
4.36 |
4.36 |
|
|
Body Length (L)mm |
41 |
61 |
81 |
101 |
|
|
Weinghtkg |
0.33 |
0.45 |
0.65 |
0.8 |
|
PLANET GEAR Electrical Specifications
|
Number of gear trains |
1 |
2 |
3 |
4 |
|
|
Reduction ratio |
3.7 ,5.2 |
14 ,19, 27 |
51,71,100,139 |
189,264,369 |
|
|
(L2) |
mm |
31 |
35.8 |
42.1 |
48.9 |
|
N.m |
0.3 |
1 |
2 |
3 |
|
|
N.m |
0.9 |
3 |
6 |
9 |
|
|
% |
90 |
81 |
73 |
66 |
|
|
g |
191 |
207 |
288 |
312 |
|
